5MP Full Colour IP Poe NVR System Kits Outdoor Waterproof Human Detection Audio Security Surveillance CCTV Camera From CCTV Surveillance Manufacturer

5MP Full Colour IP Poe NVR System Kits Outdoor Waterproof Human Detection Audio Security Surveillance CCTV Camera From CCTV Surveillance Manufacturer

4CH POE NVR Human Detection Kit with 4x 5MP POE Outdoor IR Camera MODEL:SE-332M8P4-K43B-FC Product Feature: -1x 4CH 5MP
SHARE

Description

Basic Info.
Model NO. SE-332M8P4-K43B-FC
Type Security Complete CCTV Kit
Sensor CMOS
HDMI Format 2592 X 1944
Horizontal Resolution 2592 X 1944, 5 Megapixel
Kind 3.6mm Fix Lens
Certification CE, FCC, CCC, RoHS, EMI/EMC, ISO9001: 2000
Feature Waterproof / Weatherproof, High Definition, Mini Size, Vandal-proof
Effective Distance 10-30m
Sensor Size 1/2.7" 5 Megapixel CMOS
Remote Control P2p APP, Vms, Ie
Product 4 Channel NVR Kit with 4X 5MP Poe IP Camera
OEM&OEM Yes, Customised Hardware and Software
Video Compression H.265, H.264, Mjpeg
Warranty Time Two Years
Customized Logo MOQ 50PCS
Transport Package Paper Carton
Specification Aluminium alloy
Trademark SECUMATE, OEM
Origin China
HS Code 8525801390
Production Capacity 20000 Pieces/Year
Product Description
4CH POE NVR Human Detection Kit with 4x 5MP POE Outdoor IR Camera

MODEL:SE-332M8P4-K43B-FC Product Feature:
-1x 4CH 5MP POE Port NVR(1x HDD)
-HDMI/VGA output up to 1080p preview
-4x 5MP POE Outdoor IR Camera
-4x 20m Network Cables
-1x DC48V/3A Power Adapter
-1x USB Mouse
-Plug and Play
-P2P APP (MKVSION), QR Code Scan&Add, easy for Smart Phone Connection
-------------------------------------------------------------------------------------------------------------------------------------------------------------------
Truly Plug ' n ' Play. Set up within minutes!
No experience required. Just connect the cameras to the NVR using just 1 cable for each IP camera and watch straight away.
The NVR uses POE to power the IP camera therefore you don't need to use extra cables to supply power, making installations easier and quicker.
Support P2P Phone application, allowing easier home application. Scan the unique and encrypted QR Code(in the kit) to start watching on your mobile phone, tablet etc straight away.

5MP Full Colour IP Poe NVR System Kits Outdoor Waterproof Human Detection Audio Security Surveillance CCTV Camera From CCTV Surveillance Manufacturer



5MP Full Colour IP Poe NVR System Kits Outdoor Waterproof Human Detection Audio Security Surveillance CCTV Camera From CCTV Surveillance Manufacturer




5MP Full Colour IP Poe NVR System Kits Outdoor Waterproof Human Detection Audio Security Surveillance CCTV Camera From CCTV Surveillance Manufacturer


5MP Full Colour IP Poe NVR System Kits Outdoor Waterproof Human Detection Audio Security Surveillance CCTV Camera From CCTV Surveillance Manufacturer


5MP Full Colour IP Poe NVR System Kits Outdoor Waterproof Human Detection Audio Security Surveillance CCTV Camera From CCTV Surveillance Manufacturer



Camera
Image Sensor 1/2.7" 5 Megapixel CMOS
Effective Pixels 2592 x 1944
Min. illumination 0Lux/F1.4 (IR ON)
Electronic Shutter Auto/manual (1/25s-1/10000s)
Day/Night Auto/Color/ B/W EXT
Lens 3.6mm
IR Distance 10-20m
Video Parameter DWDR, Mirror, 3DNR, Sharpness, Brightness
Protection IP66
Power supply POE, DC12V
NVR
Video Input 4CH
Video Compression H.264
Video Input Resolution 5MP/4MP/3MP/1080P/960P/720P/D1/VGA/4CIF/DCIF/2CIF
Video Output VGA/HDMI sync output,
1920×1080,1440×900,1280×1024,1366×768,1024×768,800×600
Bit Rate 16-8000Kbps
Image Display 1/4/6/8/9 screens
Snapshoot Support(BMP)
Motion Detection 396(22*18)areas available to setup and multi sensitivity adjustable
Video Frame Rate 1-30fps
Record Mode Manual/Alarm/MD/Regular
Playback Synchronic 1ch Main strea, 4ch Sub stream
Search Method Time, Calendar, Event, Channel
Video Playback Start, Stop, Fast play,Slow play, Frame play, Snapshoot, Full screen, Precise playback
Backup location Local HDD, Network
Backup Method Network, USB storage device, USB recorder
Network Protocol TCP/IP, HTTP, DDNS, SMTP(SSL), DHCP, PPPOE, UPNP, NTP, P2P, ONVIF
Connect protocol I8S, ONVIF
Smart Phone iPad, Android
Brower IE, Chrome, Firefox, Safiri
Intelligent Detection Motion detection. Video loss, Video privacy, shelter alarm
Other /
Network Interface RJ45 10M/100M adaptive Ethernet port
POE port 4
Alarm input /
Alarm output /
RS-485 Support
USB Port 2*USB2.0
e-SATA /
HDD 1 SATA, up to 8TB
Working Temperature -20°C ~ 55°C/10%--90%
Power Supply DC48V/3A, POE
Power Consumption NVR:<10W(Without HDD)
Dimension(mm) NVR: 300(L)x209(W)x48.5(H)mm IPC: 75(H)*Φ93(D)mm
